Pathway Grids
Prices From £10.00 Per SQM
Gravel pathways can be a nightmare to navigate for anything on wheels, from vans, lorries and cars to buggies, wheelchairs, and mobility scooters.
However, with the ECOMOBILITY path grid, navigating a gravel surface couldn’t be easier.
Deliveries are made by National 24 hour express couriers to provide you with a speedy and efficient service.
The time frame for delivery is usually within 3 working days from order point. Saturday/Sunday and Bank Holidays are not classed in those working days.
How much gravel do I need?
How much gravel do I need?
Please use this gravel calculator to calculate how much gravel you will need for your ground reinforcement grids. The grids can be filled with a wide range of materials including soil, grass, grass seed, gravels, stones and more. For our 40mm grids, we recommend using 5-25mm angular stone gravel and for our 50mm grids we recommend using 5-30mm angular stone gravel.
X
kg needed for square metres
How much do I need?
Please use our square meter calculator to calculate how many Grids you need for your ground reinforcement project. Please enter the width in metres and the length in metres to find out your desired square meterage. If you require further help and information, please contact our helpful sales team on +44 (0) 1773 875 255 or customerservices@ecodeck.biz.
X
You will need square metres
We have created a product that allows for easy navigation of a wide range of graveled areas, allowing access where there maybe wasn’t any before! The grids are built to last, serving families, businesses and public areas for many years.
Durable installation
Our Pathway Grid is an extremely robust and long-wearing and is designed to cover the surface of any graveled area to make it easier to cross over. These powerfully built, UV-stable gravel pathway grids create a smooth, stable, and perfectly flat surface that can carry up to 25 tonnes of weight from a wide range of vehicles, including lorries, vans, and cars.
Multipurpose installation
These multipurpose path grids can be used for a variety of applications depending on the size you choose. Our most popular model is 500x500x40mm and is suitable for both domestic and light industrial surface reinforcement.
The modular design of our gravel pathway grids means that you can add to the installation at any point to expand its surface area. With an easy-to-use push-snap fixing, similar to a jigsaw, you can create the formation of your own design and click it together with no hassle at all.
High-quality finish
The Pathway Grid is designed in an open cell structure to allow it to slot cleanly over grass seed, soil, or gravel of between 5mm to 35mm to give it a neat finish. The open cell structure of our path grids also provides added stability while preventing your chosen infill material from migrating downward or laterally to keep it compact and secure.
Eco-friendly materials
This expertly designed product is not only sturdy and built to last, but it’s also self-draining and made of recycled plastic, so you can rest assured that it has a minimal impact on the environment. As a part of our range of permeable paving products, the Pathway Grid has been designed in compliance with Sustainable Urban Drainage Solutions (SUDS) regulations.
To learn more about our Pathway Grids, don’t hesitate to get in touch with our friendly and professional team by giving us a call on 01773 875255 or by dropping us an email at sales@ecodeck.biz today.
Additional applications uses& suggested
- An Eco friendly sustainable grass & gravel paving & structure support solution
- Ground stability grids installed at ground level, to reduce the effect where vehicle and foot traffic pass over by stopping the ground from churning up. Access roads & emergency service lanes (fire & ambulance access routes)
- Driveway grids & gravel parking
- Grass or gravel car parks or temporary & permanent over-spill parking solutions
- Driveways and residential lawn/gravel parking reinforcement
- Anti storm – flood surface drainage solutions
- Water run off safety solutions & French drains
- Railway embankment stability
- Slope and embankment reinforcement
- Melioration ditches
- Horse stud, ménage and paddock use
- Buggy paths
- Disability access routes
- Golf courses paths & grass stabilisation
- School play area and access routes
- Event*/marquee flooring solutions
- Grassed garden banks
- Lawn protection
- Trellis supports & much more.
If you have already purchased one of our products, please activate your warranty here.
Technical Specifications
| Material | 100% recycled, black, non toxic, UV stable PP/PE blend |
|---|---|
| Dimensions | 500mm x 500mm x 40mm |
| Rib wall thickness | 3.5mm |
| Weight/m2 | 4kg |
| No Grids/m2 | 4 |
| Filling | Gravel, Stone, Grass, Grass Seed, Soil, 3mm-30mm |
| Temperature Stability | -50 to +90C |
| Fitting | 4 integrated V force push fit locking connections per side |
| Environmental | Complies with S.U.D.S & Flood & Water Management Act 2010 |
| Country of Manufacture | UK |
| Shipping Details | 260 grids / 65 sqm per pallet 500 tonnes load capacity |
| Vehicle Testing | Tested to withstand vehicles up to 30 tonnes |
| Compression Test | 500 tonne |
| Axle Load | 30 tonnes |
| Extra | Built in anti-migration cell bottom lattice and anti-gravel movement ribs, cell-wall topped anti-slip nodules. Used on slop inclines of in excess of 1 in 4. |
What are S.U.D.S
S.U.D.S infoEcodeck are proud to offer a sustainable solution to SuDS. SuDS are a nature-based solution to drainage problems. They reduce the impact of rainfall, for example by using grassed and other permeable surfaces, creating rain gardens, or building attenuation ponds in order to reduce the potential for surface water or river flooding. The excess rainfall is captured and then slowly filtered into the ground.
How to use
To start you installation Download the easy-to-follow guide to laying the Ecodeck.
